DMLS - Maraging Steel

Maraging Steel

Strength, Hardness, Ductility

Maraging Steel is a high-strength alloy known for its exceptional mechanical properties and excellent resistance to corrosion. It is typically produced through a process called precipitation hardening, which involves aging the material to achieve its desired strength.

The name "maraging" is derived from the combination of "martensite" and "aging." The alloy initially undergoes a solution treatment to form a supersaturated solid solution, followed by a rapid cooling process to transform the structure into martensite. Subsequently, the material is subjected to a low-temperature aging process, which leads to the precipitation of intermetallic compounds. This aging process enhances the strength and hardness of the material while maintaining its ductility.

Applications

  • Aerospace:

    Maraging Steel is widely utilized in aerospace applications due to its high strength, excellent mechanical properties, and good corrosion resistance. It is used in the manufacturing of aircraft components, rocket engines, landing gear parts, and structural components.

  • Tooling and Molds:

    Maraging Steel is favored in tooling and mold making industries due to its high hardness, wear resistance, and dimensional stability. It is used to create molds, dies, and tooling inserts for injection molding, blow molding, and extrusion processes.

  • Automotive:

    Maraging Steel finds applications in the automotive industry, particularly in areas that require high strength and durability. It is used in the production of engine components, transmission parts, suspension components, and safety system components.

  • Defense and Military:

    The excellent strength and toughness of Maraging Steel make it suitable for defense and military applications. It is used in the manufacturing of weapon systems, armored vehicles, ballistic protection, and other critical components that require superior performance.

  • Medical:

    Maraging Steel is employed in the medical field for the production of surgical instruments, orthopedic implants, and medical device components. Its biocompatibility, strength, and corrosion resistance make it a suitable choice for these applications.

  • Energy:

    Maraging Steel is utilized in the energy sector for various applications. It is used in the production of components for power generation equipment, oil and gas exploration tools, and renewable energy systems.

Technical Information

Property Value
Tensile Strength Typically ranging from 1000 MPa to 2000 MPa
Yield Strength Typically ranging from 800 MPa to 1600 MPa
Elongation Typically ranging from 5% to 15%
Hardness Typically ranging from 30 HRC to 50 HRC (Rockwell hardness)
Density Approximately 7.8 g/cm³
Melting Point Approximately 1410°C to 1440°C (2570°F to 2620°F)
Thermal Conductivity Approximately 14.7 W/m·K
Coefficient of Thermal Expansion Typically around 10.3 µm/m·K
Specific Heat Capacity Approximately 460 J/kg·K
